The parallel smooth jaws of the Joker 6004 allow surface pressure and can thus prevent rounding of the bolt or screw head, which can occur during power transmission via the corners.
- 6 self-setting spanners with ratchet functionality
- For hexagon screw heads and bolts with sizes 7-32 or 1/4"-1 1/4" (imperial) and all intermediate sizes
- Automatically and continuously gripping hexagon screws and bolts
- Lever mechanism upon gripping prevents slipping and damage
- With mechanical ratchet functionality for fast and consistent screwdriving without removing the spanner
- Return angle of only 30° when using the corner-width rectangular prisms in the jaw
- Textile robust roll pouch
Product features
Joker 6004: automatically and continuously self-setting
With its automatically and continuously gripping parallel jaws the Joker spanner 6004 covers all dimensions in the respective field of application. The tool automatically finds the required size when placed on the bolt or screw, no setting required.
Joker 6004: gentle to the screw
Joker 6004: Ratchet mechanism for quick working
The ratchet feature in the jaw ensures fast and consistent screwdriving without removing the tool.
Joker 6004: low return angle
The corner-width rectangular prisms in the jaw allow a return angle of only 30°.
Textile robust roll pouch
Storage and transport in a robust and compact textile roll pouch, so the tool is always close at hand.
Pouches made of mesh material
The mesh pouches hold the tools securely and reliably. The size marking can be seen through the mesh material.
Find out more about this product
Product description
6-piece set. Joker 6004 self-setting spanners with ratchet functionality. With its continuous and parallel jaws, the tool replaces several single wrench sizes. For metric (7.0 to 32.0 mm) and imperial (¼" to 1 1/4") hexagon screws and bolts. The required size is automatically and continuously set when attaching the tool to the hexagon bolt or screw. The integrated lever mechanism securely clamps the hexagon screw or bolt between the jaws, which significantly reduces the risk of slippage or damage. The ratchet feature ensures fast and consistent screwdriving without removing the tool. By using the corner-width rectangular prisms, a return angle of only 30° can be achieved. The single-arm design, in conjunction with the ratchet feature and the corner-width prism, makes it possible to work even in confined spaces. In a robust roll pouch.
Tools in this set
17; 8; 9; 10 x 1/4; 5/16; 3/8“" x 117 mm
05020099001
110; 11; 12; 13 x 7/16; 1/2" x 154 mm
05020100001
113; 14; 15; 16 x 1/2; 17/32; 9/16; 19/32; 5/8" x 188 mm
05020103001
116; 17; 18; 19 x 5/8; 11/16; 3/4" x 224 mm
05020101001
119; 20; 21; 22; 24 x 3/4; 25/32; 13/16; 7/8; 15/16" x 256 mm
05020104001
124; 27; 30; 32 x 15/16; 31/32; 1; 1 1/16; 1 1/8; 1 3/16; 1 1/4" x 322 mm
05020102001
